CA95CNC Automatic Roundness Measuring Machine

Product Feature
●Using the radius measurement method, the workpiece is rotated
●Using high precision air float spindle as reference
●It is composed of imported precision circular grating, precision inductance displacement sensor and computer
●Measurement of angular and radial displacements of the measured workpiece to ensure the accuracy of the angular displacement and radial value of the measured workpiece
●Measurement software adopts the CA system measurement software based on the Chinese version of Windows operating system platform to complete data acquisition, data processing and printout work.
Product Application
●This machine is widely used in industries such as machining, automotive and motorcycle parts, bearings, motors, power tools, precision tools, precision hardware, cutting tools, molds, and optical components.
●It is also utilized in research institutes, universities, metrology organizations, and corporate metrology laboratories. Additionally, it serves military enterprises in the aerospace sector.
状态:
数量:

产品描述

Technical Parameters

Item

Parameter

Measurement Range

Maximum Diameter

Ф500mm

Minimum Inner Diameter

Ф2mm

Maximum Height

500mm

Spindle Accuracy

Radial Error

±(0.025+5H/10000)μm

Axial Error

±(0.02+4X/10000)μm

Parallelism between Rotary Axis and Z-Axis Guideway

1μm/400mm

(Busbar Reference)

Worktable

Tabletop Diameter

Φ280mm

Tabletop Diameter

Φ500mm

Load Capacity

50Kg

Adjustment Range

Adjust the eccentricity ±2mm; adjust the level ±1°

Adjustment Mode

Automatic/Manual

Spinning Speed

6rpm(0-12 rpm Adjustable)

Column

Straightness

(Narrow Range)

0.35μm /100mm

Straightness

(Full Range)

0.6μm /400mm

Horizontal Arm

Horizontal Moving Range

180mm

Moving Speed

0.5-6mm/s or Manual

Mobile precision

≤2μm/150mm

Sensor

Range

600μm (Radius Difference)

Resolution

0.001μm

Stylus Shape

φ2mmRuby tip

(φ1mm、φ0.5mm Optional)

Sensor Direction

/ Adjustment Angle

Bidirectional/±45

Data Acquisition

Imported grating 14400 points/cycle

Magnification

Up to 200,000x, adjustable

Aligning and Levelling Mechanism

Stylus Shape(mm)

Φ280mm

Aligning and leveling mode

Automatic/Manual

(can be switched freely)

Aligning and Leveling Range

Aligning:±3mm

Leveling :±1°

Table Runout

Mesa flatness (um)

≤0.005mm

≤0.003mm

Bearing

>50KG

Packing List

Mechanical Part

Host instrument stand

Granite table

High precision air bearing spindle

Air Float Column System

Column grating

Cross rail moving device

Centering & Leveling Worktable

Ф280mm、160mm

Table Diameter Ф280mm,

Table Height 138mm

Adjustment Range:

Eccentricity :±2mm;

adjustment level: ±1°

Precision three-jaw chuck

Model CF1-A3

Outer size clamping range:

Ф1 mm~Ф100mm

Inner size clamping range:

Ф36 mm~Ф90 mm

Air Filtration System

1 set

Electrical Part

Electrical Control System

1 set

High Precision Rotary Circular Grating Encoder

1 set

Inductance Sensor

1 set

Extended Sensor Mounting Bar

1 set

Φ2x10mm  Ruby Needle

1 pc

Computer Industrial Computer

i5 3.0G /RAM 8G/

Hard Disk 1T/Main Board 970

1 set

Monitor (Brand: Lenovo)

24 inches

Wireless Mouse and Keyboard (Brand: Lenovo)

1 set

HP Color Ink Jet Printer(Brand: HP)

1 set

Measuring Software

1 set

Standard Component

Oval Standard

1 set

Cylindrical Standard

1 set

Documentation

Use Chinese Version Instruction Manual (Including Electronic Version)

1 copy

Product Warranty Card

1 copy

Product Packing List

1 copy

Product Certificate

1 copy

Equipment Acceptance Sheet

1 copy

Work-Box

1 set
